| Price: | Negotiable/Piece |
|---|---|
| Min Order: | 200/Piece |
| Pay Type: | T/T,Paypal |
| Prod Model: | 5012 |
|---|---|
| Bearing Type: | Ball Bearing and Sleeve Bearing |
| Startup Voltage: | 5V/12V |
| Speed: | 3500-5000rpm |
| Noise: | 21-30dba |
| Weight: | 20.00g |
| Warranty: | 3 Year for Ball Bearing and 1 Year for Sleeve |
| Packing: | Carton |
| Delivery Time: | Shipped in 14days After Payment |
| Blade Material: | Plastic |
| Electric Current Type: | DC |
| Certification: | Ce RoHS UL |
| Model | Rated Voltage (VDC) | Startup Voltage (VDC) | Currend Amp (A) | Speed (rpm) | Air flow (CFM) | Static Pressure (Inch-H20) | Noise Level (dB-A) | Weight (g) |
| () | () | () | () | () | () | () | () | () |
| XYJ05B5012H | 5 | 3 | 0.3 | 5500 | 13.2 | 3.33 | 32 | 20 |
| XYJ05B5012M | 5 | 3 | 0.2 | 4500 | 11.08 | 2.52 | 28 | 20 |
| XYJ05B5012L | 5 | 3 | 0.14 | 3500 | 8.96 | 1.61 | 21 | 20 |
| XYJ12B5012H | 12 | 6 | 0.13 | 5500 | 13.2 | 3.33 | 32 | 20 |
| XYJ12B5012M | 12 | 6 | 0.08 | 4000 | 11.08 | 2.52 | 28 | 20 |
| XYJ12B5012L | 12 | 6 | 0.07 | 3500 | 8.96 | 1.61 | 21 | 20 |
| XYJ24B5012H | 24 | 10 | 0.08 | 5500 | 13.2 | 3.33 | 32 | 20 |
| XYJ24B5012M | 24 | 10 | 0.06 | 4500 | 11.08 | 2.52 | 28 | 20 |
| XYJ24B5012L | 24 | 10 | 0.05 | 3500 | 8.96 | 1.61 | 21 | 20 |
Packaging details:
Two layer packaging, pcs/CTNPackaging size:
43*28*43CM
Lead time:
1. Samples within 4 days
2. Mass production within 7-10 days
3. If do the waterproof fan need 1 week more
Express:
Optional functions:
-1. Waterproof function with IP55 or IP67 level
-2.Auto-restart function
-3.Stopage Alarm function(RD function with 3 lead wires)
-4.Speed detection function( FG function with 3 lead wires)
-5.Temperature control speed function(PWM function with 4 lead wires)
Optional bearing types:
-1.Sleeve bearing(lower price):The sleeve was inported from Germany with stalbe performance and easy installation
-2.Ball bearing(high price):we use the NSK ball which is imported from Japan,it is charactered with high quality,low noise level and easy installation.
Guarantee:
-3 years warranty for ball bearing fans
-1 year warranty for sleeve bearing fans
Question & answer:
-1. What kind of cooling fans or centrifugal fans are supplied by your company?
Answer: we can provide DC cooling fan, AC cooling fan, EC cooling fan and blower fan.
-2. What kind of information should be provided by the customer before order?
Answer : please kindly advise Size, Rated voltage, Bearing type, Speed or air flow,Lead wires.
-3. How many kind of bearings for cooling fans are there in your compnay at present?
Answer : now we have two types bearing for the fan, sleeve bearing and ball bearing.
-4. How to detect the data of cooing fan in your company?
Answer: the speed and voltage are detected by the tachometer, air flow is found by wind tunnel.
-5. How to control the quality of products in your company.
Answer: 100% total testing before each fan dispatched.
