320X240 2.8 Inch Small Size LCD Display
| Price: |
US $ 3.98-4.98/Piece |
| Trade Terms: |
FOB |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
Product Specifications
| Prod Model: |
TFT072A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
2.8inch TFT Touch Display |
| Resolution: |
240X320 |
| FPC Cable: |
37 Pin |
| IC: |
Driving IC:Ili9341 TFT Controller & Drive |
| Screen Size: |
≤17" |
| Application: |
Mobile Phone |
| Aspect Ratio: |
16:9 |
| Feature: |
Touch Display |
| Type: |
TFT |
| Widescreen: |
Not Widescreen |
| Response Time: |
6ms |
| 3D: |
Not 3D |
| Interface Type: |
RGB |
| Optimum Resolution: |
320X240 |
Product Description
320X240 2.8 Inch Small Size LCD Display2.8", 240 x RGB x 320 dots, 262k colors, transmissive, TFT LCD module.
Viewing angle: 12 o'clock.
Logic voltage: ~2.8V.
White LED backlight.
FPC connection.
"RoHS" compliance.
Driving IC:ILI9341 TFT controller & drive
Data interface: 8080 system8/16-bits parallel interface
Outline dimensions: 50(W) x 69.2(H) x 4.2(D) mm
Active area: 43.2(W) x 57.6(H) mm
Display format: 240 x RGB x 320 dots
Color configuration: RGB stripe
TFT: 240xRGBx320
Dot pitch: 0.18(H) x 0.18(V) mm
Weight: TBDFAQ | Q1:Are you a factory or trading company? | A1: We are manufacturer.
Please refer to our company show |
| Q2:Where is your factory located?How can I visit there? | A2:Our factory is located in Hunan,China.Welcome to visit our factory.
We could pick you up in Changsha Huanghua Airport, or High-speed train
Zhuzhou Xi station. |
| Q3:How can I get some samples? | A3:We don't provide free one, but we will minus the extra price when you
reorder with the suitable quantity. And you will win the 1-3% discount. |
Q4:How does your factory do regarding
quality control? | A4:Quality is the priority.
Our factory has gained ISO9001 RoHS SGS certification. |
| Cooperate Supplier | Tianma, Innolux, Sumsung, LG, Varitronix, CPT, BOE,HSD,Chi mei |
| Company development plan | Our company prepared attend electronics show in Korea,2017 |
3. Related Products | 1. Chracter lcd (8x1, 8x2, 16x1, 16x2, 16x4, 20x2, 20x4 , etc.) |
| 2. Graphic lcd (122x32, 128x64, 192x64, 240x128, 320x240 , etc.) |
| 3.TFT LCD (1.44", 1.77", 2", 2.2",2.4", 2.8", 3",3.2", 3.5", 4.3", 5", 5.5", 5.7", 6.2", 7", 8", 9", 9.7".10.1", 10.2", 10.4",17", etc. |
| 4. TN/STN/HTN/VA segment custom lcd,LED backlight panel |
| All kinds of LCD Module can customize according to customer`s requirement. |
Safety
Liquid crystal is poisonous. Do not put it in your mouth. If liquid crystal touches your
skin or clothes, wash it off immediately by using soap and water.
1. Store the module in a dark room where must keep at 25±10ºC and 65%RH or less.
2. Do not store the module in surroundings containing organic solvent or corrosive gas.
3. Store the module in an anti-electrostatic container or bag.
Application:
Autoelectronics,3D&Shutter,Meters&Instrument,Telecommunication,Domestic electrical appliance(Household appliance), Fuel dispensers, Office equipment, Medical &health equipment, Business related facility, Education electronics
