| Price: | US $ 0.92-0.98/Piece |
|---|---|
| Min Order: | 1000/Piece |
| Pay Type: | L/C,T/T |
| Prod Model: | YK9034 |
|---|---|
| Usage: | Workstation |
| Type: | Wired |
| Support Network: | Ethernet |
| Information Content: | Short Message |
| Certification: | RoHS |
| Condition: | New |
Cables include: CAT5e/CAT6 /CAT7
UTP/FTP/SFTP.
Conductor materials: CCAG, CCAG, CCA,4 CCA + 4 CCS, 4 CCA.
Conductor diameter: single chain: 0.40mm / 0.45mm 0.56mm / 0.57mm / 0.58m
Stranding: 7 * 0.12 mm / 7 * 0.16 mm / 7 * 0.20 mm
Shield: aluminum foil, aluminum foil + weaving
Grid: 32 eyes, 48 nets, 64 eyes, 80 eyes, 96 eyes, 112 eyes, 128 eyes
Knitting materials: copper, CCAG, CCA,CCA 4 + 4 CCS;
Insulation materials: polyethylene; Environmental sports;
Protective cover: green PVC; New materials; LSZH; ROHS. CM; Outdoor; And so on
Transmission rate: 1000base-t Ethernet (1000Mbps)155MbpsATM, 100mbpstp-pmd,
The 100Mbps Ethernet (100base-t) transmission rate is as high as 622Mbps, as well as other system applications; 10 MBPS Ethernet
Color: grey, black, white, blue, yellow, red, green, etc.
Application: exports, trade, coffee shops, schools, enterprises, government, Banks, buildings and other network engineering systems.
Structure:
| Product model | UTP-11-6-4P |
| Diameter of copper cable | 0.57mm±0.005 |
| Diameter of insulated wire | 1.0mm±0.03 |
| Insulation mark | Orange, orange white, blue, blue white, green, green white, brown, brown white |
| Sheath thickness | 0.62±0.05mm |
| Sheath diameter | 6.5±0.2mm |
| Sheath material | PVC (Polyvinyl Chloride) |
| Rip cord | Three-ply twisting |
| Standard weight of cable | 14.3KG/box±0.2 |
| Cable package | 305m/box |
Product information:
| Product description | Product model | Sheath material | Sheath color | STANDARD PACKING |
| Indoor cat6e 4-pair unshielded twisted pair | UTP-11-6-4P | PVC | Fleet Blue | 305m/box |
| Indoor cat6e 4-pair low-smoke zero-halogen (LSOH) unshielded twisted pair (UTP) | UTP-21-6-4P | LSZH | Grey | 305m/box |
| Outdoor cat6e 4-pair unshielded twisted pair | UTP-31-6-4P | PE | Black | 305m/box |
| Indoor cat5e 4-pair unshielded twisted pair | UTP-11-5E-4P | PVC | Fleet Blue | 305m/box |
| Indoor cat5e 4-pair low-smoke zero-halogen (LSOH) unshielded twisted pair (UTP) | UTP-21-5E-4P | LSZH | Grey | 305m/box |
| Outdoor cat5e 4-pair unshielded twisted pair | UTP-31-5E-4P | PE | Black | 305m/box |
FAQ
Q1. What kind of products can your company supply?
A: We specialize in supplying network cable, coaxial cable, HDMI cable, VGA cable, telephone cable, speaker cable and ect.
Q2. What's your MOQ?
A: The MOQ of long meter cable is 50 km, or we can negociate.
Q3. What's your delivery time?
A: Our delivery time is about 15-20 days after comfriming the deposite, it is based on the quantity of the order.
Q4. What are your payment terms?
A: Normally, we accept T/T in advance, as for other payment term, we can negociate with you.
Q5. What's your trade term ?
A: We can accept FOB, CIF, EXW term.
Q6. What's your conventional packing ?
A: 100m/plastic or wooden drum, 305m/wooden drum or color box. However, we can produce according your demand.
Q7. Can your factory customize cables based on clients' samples or data sheet ?
A: Yes, we can.
