Product Specifications
| Prod Model: |
HSGP-4.5KB |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engraving Machine Type: |
Laser Engraving Machine |
| Control: |
Automatic |
| Current: |
AC |
| Laser Type: |
Diode |
| Usage: |
Crystal, Glass, Acrylic |
| Maximum Pulse Speed Points: |
300,000dots/Min |
| Device Input Power: |
AC220V / 110V ± 10% 50-60Hz |
| Coolingt: |
Air Cooling |
| Laser Frequency: |
4,000Hz |
| Maximum Engraving Scope: |
300mm X 400mm X130mm |
Product Description
3D Crystal Laser Engraving Machine HSGP-4KB
Higher speed & Larger engraving scope & Integrated computer
2D/3D engraving
Max. engraving speed: 300,000dots/min
Max. engraving scope: 300mm x 400mm x 130mm
Engravable materials: Crystal, Glass, Acrylic
FC, FDA, CE, SGS, TUV approved
Two years warranty for whole machine
Exellent service after-sales
Holy Laser is the leading manufacturer of lase engraving machine worldwide.
We are recuiting the agents and distributors for overseas market
Technical Parameter
|
HSGP-4.5KB |
| laser / laser wavelength | semiconductor diode/ 532nm |
| laser repetition frequency | 4,000hz |
| marking speed | 300,000dots/min. |
| max. marking scope | 300*400*130mm |
| focus diameter/resolution | 0.02nm/ 800DPI |
| working | with high speed scanner+X+Y+Z (5 axis) |
| positioning accuracy | 10μm |
| continuous working time | 24 hours |
| coolinf/quality warranty | air colling |
| lifetime | more than 20,000hours |
| gross power/noise |
1.5KW/ 50db |
| power requirement | single phase 220V or 110 V (+/- 10%), 50Hz or 60 Hz |
| software |
1. for dots cloud file
2. for machine control
|
| suitable materials | Crystal, Glass, Acrylic, etc. |
opertation conditions |
temperature10-28°C, humidity <85% no condensation |
Operation system |
Windows XP, Windows 7 |
Zhejiang Holy Laser Technoloy Co., Ltd, is a factory Located in YiWu City, ZheJiang Province. We specialize in: 3D laser machine, Large size glass engraving machine, Laser marking machine, Laser cutting machine, etc.
We are here because we are qualified for serving you by the bellow advantages:
1, We can supply machine in 7-10days once you confrim the order.
2, We supply complete service: Machine, design, crystal and LED base factory info. Design for free, technology support for all liftime, training for free.
3, We have our own factory garden that more than 1600squre meter. Wihch suport by government in yiwu economic development zone.
4, All our productions with CE, FCC, FDA, SGS, TUV certification s. Cause suitable for all city in the world.
5, We also have our son desiner team which have more than 15 years experience. Can supply you 2D or 3D desing with your special photo or supply beautiful design in tock.
You are always welcome to visit our factory in any time, , you are here not just our customer, most important is we are friends.
