| Price: | US $ 3300-5000/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | T/T,Western Union,Paypal |
| Prod Model: | OD-1390L |
|---|
Applicable Industries:
Garment,leather,cloth toys,computer embroidery cutting,mould,crafts,bamboo and wood, advertising and building decoration,packaging and printing ,paper products,etc.
Applicable Materials:
Rubber,plastic,cloth,leather,woollens,crystal,organic glass,tile,jade,bamboo and wooden products,etc.
Technical Parameter:
| Technical Parameter: | |
| Model number | OD-1390 |
| Whole machine size | 1,760 x 1290 x 1,070mm |
| Engraving size | 1300 x 900mm |
| Table | Honeycomb |
| or Blade shape | |
| Laser tube | Sealed CO2 glass laser tube |
| Laser power | 60W for engraving |
| 80W for cutting | |
| Working voltage | AC 110 - 220V ±10%, 50 - 60Hz |
| Total power | <1,000W |
| Engraving speed | 0 - 60,000mm/min |
| Re-position accuracy | ±0.05mm |
| Control | DSP system with USB interface |
| Operating temperature | 0 - 45°C |
| Operating humidity | 5 - 95% |
| Minimum shaping character | English 1 x 1mm |
| format | BMP, PLT, DST, DXF, and AI |
| Driving motor | Stepper |
| Cooling | Water cooling |
| Auxiliary equipment | Exhaust-fan, air-exhaust pipe |
| Software provided | Laser Cut 5.3 |
| Control panel | English |
| Compatible software | CorelDraw / AutoCAD / Photoshop |
| Net Weight | 220KG |
1, Front and back both sides open allow large pieces be put in and engrave.
2, U flash Disk Supported: Read files directly from U-flash disk, you can work even without PC!
3, with function of restoring from power-off, continue working from break point.
4, Transmit files directly from Corel draw and Auto CAD, Photoshop,etc.
5, We adopt CW5000 industial chiller for laser tube cooling,gurantee good working effect.
6,For cutting wood,plywood,cardboard,etc flammable materials,we suggest adopt air compressor,provent burn or fire from materials surface.
